| Place of Origin | Guangdong, China |
| Brand Name | LIONLED |
| Certification | CE,FCC,ROHS,UL,PSE |
| Model Number | P2.5 |
Product Details
| Pixel | P2.5 | P2.604 | P2.976 | P3.91 | P4.81 | P5.2 | P6.25 |
| Module resolution(W*H) | 100*100 | 96*96 | 84*84 | 64*64 | 52*52 | 48*48 | 40*40 |
| Module size(W*H*D) mm |
250*250*18 | ||||||
| Panel resolution(W*H) | 200*200 | 192*192 | 168*168 | 128*128 | 104*104 | 96*96 | 80*80 |
| Panel size(W*H*D)mm | 500*500*78 500*1000*78 |
||||||
| Resolution(dot/m²) | 160000 | 147456 | 112896 | 65536 | 43264 | 36864 | 25600 |
| Protection level | Indoor(front IP54,backIP43) | ||||||
| White balance brightness (nits) |
Indoor ≥1300 | ||||||
| Color temperature(K) | 6000—9300 adjustable | ||||||
| View angle(°) | >120 | ||||||
| Power consumption (A/unit module) |
DC 6～7 | ||||||
| Peak power consumption (W/m²) |
800/300 | ||||||
| Average power consumption(W/m²) |
|||||||
| Power requirements | AC100-240V | ||||||
| Drive method | Constant current drive | ||||||
| Frame frequency(Hz) | 50&60 | ||||||
| Refresh @60Hz frame signal input |
≥3840/≥7680 | ||||||
| Life typical value(hrs) | 100,000 | ||||||
| Work temperature(℃) | -20-55 | ||||||
| Storage temperature(℃) | -30-60 | ||||||
| Defective ratio | ≤4/100000 | ||||||
| Interaction | Interactive/Non-Interactive | ||||||
